The Closed Circuit Pattern: Why Your Users Get Stuck (And How to Prevent It)

Ever opened a modal and couldn't close it? That's a broken circuit. We made it impossible to build those.

Orbital Unit = Entity + Traits + Pages

The Stuck User Problem

You're using an app. You click "Open Settings." A modal appears. You click the X button. Nothing happens. You press Escape. Nothing. You click outside the modal. Still nothing.

You're stuck.

This happens because:

1. The modal opened via internal state (setIsOpen(true))
2. The close button triggers setIsOpen(false)
3. But if there's a bug, the state doesn't update
4. Or worse — the close button was never wired up

In Almadar, this is architecturally impossible.

The Closed Circuit Principle

Every UI interaction must complete a full circuit back to the state machine.

┌────────────────────────────────────────────────────────────────┐
│                                                                │
│   User Click ──► Event Bus ──► State Machine ──► UI Update     │
│       ▲                                              │         │
│       └──────────────────────────────────────────────┘         │
│                                                                │
└────────────────────────────────────────────────────────────────┘

No shortcuts. No direct state mutations. Every action flows through the circuit.

How It Works in Almadar

1. User Triggers Event

When you click a button:

// ❌ NOT this:
onClick={() => setIsModalOpen(false)}

// ✅ This:
onClick={() => eventBus.emit('UI:CLOSE')}

The component doesn't know what happens next. It just emits.

2. Event Bus Routes to State Machine

The event bus receives UI:CLOSE and routes it to the active trait's state machine.

3. State Machine Processes

{
  "from": "modalOpen",
  "to": "browsing",
  "event": "CLOSE",
  "effects": [
    ["render-ui", "modal", null],
    ["render-ui", "main", { "type": "page-header", ... }]
  ]
}

The state machine:

1. Transitions from modalOpen to browsing
2. Clears the modal slot
3. Renders the main content

4. UI Updates

The component re-renders based on the new state. The modal disappears because the state machine said so.

Why This Prevents Stuck States

1. Events Must Have Transitions

If you define a button with an event:

{
  "type": "page-header",
  "actions": [{ "label": "Open", "event": "OPEN_MODAL" }]
}

The validator requires a matching transition:

{
  "from": "browsing",
  "to": "modalOpen",
  "event": "OPEN_MODAL"
  // ✅ Required transition exists
}

If you forget:

✗ Error: CIRCUIT_ORPHAN_EVENT
  Action 'Open' emits event 'OPEN_MODAL' which has no transition handler

2. Overlay Slots Must Have Exits

If you render to modal or drawer, the validator requires an exit:

{
  "from": "browsing",
  "to": "modalOpen",
  "event": "OPEN_MODAL",
  "effects": [
    ["render-ui", "modal", { "type": "form-section", ... }]
  ]
}

Must have:

{
  "from": "modalOpen",
  "to": "browsing",
  "event": "CLOSE"
  // ✅ Required exit transition
}

If you forget:

✗ Error: CIRCUIT_NO_OVERLAY_EXIT
  State 'modalOpen' renders to 'modal' slot but has no exit transition.
  Users will be stuck in this overlay.

3. Slot Wrappers Handle Escape Hatches

Even if you forget a close button, the slot wrapper saves you:

// ModalSlot.tsx (auto-generated wrapper)
const handleClose = () => {
  eventBus.emit('UI:CLOSE');
  eventBus.emit('UI:CANCEL');
};

return (
  <Modal
    isOpen={Boolean(children)}
    onClose={handleClose}  // Escape key, overlay click, X button
  >
    {children}
  </Modal>
);

The wrapper emits the event. The state machine handles it. The circuit completes.

Real-World Analogy: Traffic Lights

Traffic lights follow a closed circuit:

Red ──(timer)──► Green ──(timer)──► Yellow ──(timer)──► Red

There's no "jump from Red to Green instantly" or "get stuck on Yellow." The circuit is closed — every state has defined transitions.

Now imagine a broken traffic light:

• Stuck on Red → traffic jam
• Stuck on Green → accidents
• Random transitions → chaos

Almadar's validator is like a traffic engineer who checks:

• ✅ Every light has transitions
• ✅ No impossible states
• ✅ Emergency modes defined

Example: Modal That Can't Break

Here's a modal implementation that's impossible to get stuck in:

{
  "states": [
    { "name": "browsing", "isInitial": true },
    { "name": "modalOpen" }
  ],
  "events": [
    { "key": "OPEN_MODAL", "name": "Open Modal" },
    { "key": "CLOSE", "name": "Close" },
    { "key": "SAVE", "name": "Save" }
  ],
  "transitions": [
    {
      "from": "browsing",
      "to": "browsing",
      "event": "INIT",
      "effects": [
        ["render-ui", "main", {
          "type": "page-header",
          "title": "Tasks",
          "actions": [{ "label": "New Task", "event": "OPEN_MODAL" }]
        }]
      ]
    },
    {
      "from": "browsing",
      "to": "modalOpen",
      "event": "OPEN_MODAL",
      "effects": [
        ["render-ui", "modal", {
          "type": "form-section",
          "entity": "Task",
          "fields": ["title", "status"],
          "submitEvent": "SAVE",
          "cancelEvent": "CLOSE"
        }]
      ]
    },
    {
      "from": "modalOpen",
      "to": "browsing",
      "event": "CLOSE",
      "effects": [
        ["render-ui", "modal", null],
        ["emit", "INIT"]
      ]
    },
    {
      "from": "modalOpen",
      "to": "browsing",
      "event": "SAVE",
      "effects": [
        ["persist", "create", "Task", "@payload.data"],
        ["render-ui", "modal", null],
        ["emit", "INIT"]
      ]
    }
  ]
}

Three ways to exit the modal:

1. Click "Cancel" → triggers CLOSE event
2. Click "Save" → triggers SAVE event
3. Press Escape or click overlay → ModalSlot emits UI:CLOSE

All three transition back to browsing and clear the modal.

The Slot Hierarchy

Different slots have different return requirements:

Slot	Type	Return Requirement
main	Primary	None — this is home base
sidebar	Secondary	Optional — can coexist with main
modal	Overlay	REQUIRED — Must have exit transition
drawer	Overlay	REQUIRED — Must have exit transition
toast	Notification	Auto-dismisses, no transition needed

Why This Architecture Matters

For Users

• ✅ Never get stuck in modals
• ✅ Consistent behavior across apps
• ✅ Predictable UI patterns

For Developers

• ✅ Bugs caught at compile time
• ✅ No manual close handler wiring
• ✅ State changes are traceable

For Teams

• ✅ Schema = documentation
• ✅ Easy to review state flows
• ✅ Onboarding is faster

Try It: Build a Break-Proof Modal

Create modal-demo.orb:

{
  "name": "ModalDemo",
  "orbitals": [{
    "name": "Demo",
    "entity": { "name": "Item", "fields": [{ "name": "name", "type": "string" }] },
    "traits": [{
      "name": "DemoTrait",
      "linkedEntity": "Item",
      "stateMachine": {
        "states": [
          { "name": "main", "isInitial": true },
          { "name": "modalOpen" }
        ],
        "events": [
          { "key": "INIT", "name": "Initialize" },
          { "key": "OPEN", "name": "Open" },
          { "key": "CLOSE", "name": "Close" }
        ],
        "transitions": [
          {
            "from": "main",
            "to": "main",
            "event": "INIT",
            "effects": [
              ["render-ui", "main", {
                "type": "page-header",
                "title": "Demo",
                "actions": [{ "label": "Open Modal", "event": "OPEN" }]
              }]
            ]
          },
          {
            "from": "main",
            "to": "modalOpen",
            "event": "OPEN",
            "effects": [
              ["render-ui", "modal", { "type": "page-header", "title": "I'm a Modal!" }]
            ]
          },
          {
            "from": "modalOpen",
            "to": "main",
            "event": "CLOSE",
            "effects": [
              ["render-ui", "modal", null],
              ["emit", "INIT"]
            ]
          }
        ]
      }
    }],
    "pages": [{ "name": "DemoPage", "path": "/", "traits": [{ "ref": "DemoTrait" }] }]
  }]
}

Compile and try it:

orbital validate modal-demo.orb  # Will fail without CLOSE transition
orbital compile modal-demo.orb --shell typescript

Try removing the CLOSE transition and validating again. The compiler won't let you create a broken circuit.

The Takeaway

The Closed Circuit Pattern isn't just a good idea — it's enforced by the compiler.

In Almadar:

• Every UI action emits an event
• Every event has a transition
• Every overlay has an exit
• Users never get stuck

Because the best way to prevent bugs isn't testing — it's making them impossible to write.
